Scan to BIM / Point cloud to BIM
Laser scan and photogrammetry data turned into accurate as-built Revit models for retrofit and renovation.
Clash it in the model, not on site.
Vertex AEC Labs builds coordination-ready BIM, from scan to BIM and LOD 500 MEP to spool drawings, for contractors, consultants and owners across four continents.
0Projects delivered
0Sq. ft. modelled
0Countries served
0BIM specialists
0Founded in Kolkata
BIM services, and only BIM
We don’t do everything. We model, coordinate and document, and we do it at the level of detail your fabricators and site teams can actually build from.
Architectural BIM modelling
Walls, floors, roofs, rooms and schedules from concept through construction documentation, LOD 100 to 500.
Structural BIM modelling
Concrete and steel frames with rebar, connections and Tekla-ready detail for reliable quantities.
MEP BIM modelling
HVAC, plumbing, fire protection and electrical routed with real equipment, supports and clearances.
Clash detection and coordination
Navisworks and ACC clash reports with owner-tagged issues, so conflicts close before the pour.
4D / 5D BIM
Models linked to schedules and cost data for sequencing, progress tracking and early budget visibility.
Shop drawings and spool drawings
Fabrication-level piping, duct and steel drawings with isometric spools, cut lists and tagged part numbers.
Facade and cladding modelling
Curtain wall, panel and cladding systems modelled with panel IDs and fixing details.
Revit family creation and CAD to BIM
Parametric, lightweight families and clean conversion of legacy 2D CAD sets into working models.
As-built, FM and COBie models
Handover models with asset data structured for facility management systems.
From input drawings to 3D model to spool drawings
Your 2D plans and design drawings go in. A coordinated, clash-checked 3D BIM model comes out, followed by fabrication-ready spool drawings with schedules, dimensions and item balloons. Click any image to enlarge it.
Selected projects
A sample of recent work across healthcare, retail, commercial, residential and mission-critical sites.
Software and standards we work in
Eight years of modelling, one habit of checking twice
Founded in 2017 in Kolkata, Vertex AEC Labs grew from a three-person Revit desk into a team of 20+ modellers, coordinators and BIM managers. Every model goes through an internal QA pass against your BIM Execution Plan before it reaches you.
We work as an extension of your team: your templates, your naming, your cloud environment, and our working window of 8:00 am to 8:00 pm IST that overlaps the UK, UAE and the start of the US day.
ISO 19650 workflowsLOD 100–500BIM Execution PlansDaily progress updates
Sectors we model
ResidentialCommercialIndustrialInfrastructureHealthcareRetail and mallsData centresHospitalityEducation
Where our clients are
USACanadaUKIrelandUAESaudi ArabiaAustraliaGermanySingaporeIndia
What project teams say
“Vertex Team is a reliable and a great support to the project! Over the time we’ve worked together, the team has consistently demonstrated dedication to work and a positive attitude. It’s been a pleasure working with Vertex AEC Labs and I’m sure they will be an asset to any team / organization.”
Clorence Tan
Project Manager, General Contractor, USA
“Vertex Team has been a blessing to work with over these past months it feels like years.
Their professionalism and postive outlook in coordination has stretched me to be better leader and communicator.
They has an extensive knowledge on Mechanical and Plumbing, BIM and technical skills second to none. I myself have learned alot from the team that I adapt in my current position.
Their work ethic is by far exceeds the expectation of the task they are dedicated, driven and wants everyone they works to succeed at a high level.”
Gary
BIM Lead, Consultancy, UK
Send us your drawings
Tell us what you need modelled. We reply with a scope and quote within one working day.
